Wifi 2.4 Ghz Patch Antenna Long Range Access Point Wireless Booster
Rectangular Microstrip
Product Description
YD----Win-win To Long
YD is a professional manufacturer of antenna in China, Established
in 2014, Which Specializes in researching & developing, producing
and marketing, WTL offers kinds of crystals in order to pace with
wide applications.whatever you do need ,standard or high-class
requirement on special fields, we will support you right quartz
crystal resonator and oscillator with 100% repliability insurance.
Website: www.sztdtx.cn
FEATURE
1.Various Applications: GPS+GLONASS,GPS+COMPASS and Multimode;
2. Various sizes: 9X9mm to 78 x 78mm;
3.Matching Study for special application is available
4.Dielectric antenna for RFID tag UHF RFID
5.Tag that can be tailor-made
ELECTRICAL SPECIFICATIONS
| Electrical Characteristics |
| Antenna |
| 1 | Antenna model | 15*15*4mm |
| 2 | Frequency Range | 1575.42MHz±1.023MHz | 1598.06MHz~1605.38MHz |
| 3 | V.S.W.R | 2.0 max | 2.0 max |
| 4 | Band With@-10dB | GPS>5MHz | GLONASS>5MHz |
| 5 | Gain | 1.0dBi@15*15mm Ground | 1.0dBi@15*15mm Ground |
| 6 | Impedance | 50Ω |
| 7 | Polarization | RHCP |
| LNA |
| 1 | Frequency Range | 1556MHz~1608MHz |
| 2 | DC Voltage | 1.5V(min) | 3.0V(typ) | 3.6V(max) |
| 3 | DC current | 7.3mA | 8.5mA | 10.0mA |
| 4 | Noise Figure | 1.0 |
| 5 | LNA Gain | 33dB@25℃,1575.42MHz 33dB@25℃,1602MHz |
| 6 | VSWR | 2.0 max |
| Material |
| No | Part Name | Spec |
| 1 | Antenna | Dielectric Ceramics |
| 2 | Ground | FR-4, |
| 3 | Cable | 105mm RF-1.13 |
| 4 | Connector | IPEX II |
| Environment Condition |
| 1 | Working Temp | -40℃~+85℃, 10%~95% RH |
| 2 | Storage Temp | -45℃~+85℃, 10%~95% RH |
Packaging & Shipping
Tray packing 50PCS/Tray 200PCS/small carton box 800PCS/big carton
box
Big box dimensions (MM):472x240x290
Customer packing is welcome
