    6DBi Dual Band Antenna , External RP SMA Black Dual Band WiFi Antenna

    Ask Lasest Price
    Brand Name : YUNDING
    Model Number : YDDB-001
    Certification : ROHS
    Price : negotiation
    Payment Terms : Western Union, T/T, MoneyGram
    Supply Ability : 300000 Piece/Pieces per Day
    Delivery Time : 4-15 work days
    • Product Details
    • Company Profile

    6DBi Dual Band Antenna , External RP SMA Black Dual Band WiFi Antenna


    6dBi 2.4GHz and 5.8GHz Dual Band WiFi RP - SMA black Antenna


    • Frequency Range: 2400--2500MHz and 5100--5800Mhz
    • VSWR: ≤2.0
    • Gain: 6dBi
    • Polarization Type: Vertical
    • Radiation:Omni
    • Connector Type: RP-SMA male or custom


    Electrical characteristics and Mechanical
    Frequency Range2400-2500Mhz and 5100-5800Mhz
    Gain6DBI
    Input Impendance50 ohm
    Connectorsma/ or others
    Cable lengthCustom
    Environment
    Working Humidity20~80%
    Maximum Input Impedance50W
    Working Temperature-40ºC~+85ºC

    Environment performance test

    Project


    Test conditionTest results

    Storage environment


    Test temperature, humidity, pressure without stated condition as follwings:1.Temperature: -30℃~+80℃;2.Relative humidity: 45%-85%;3,Pressure: 86kpa-106kpaElectrical and mechanical performance normal
    High and low temperature testHaving 5 times cycle between -40℃ to 70℃,Then in common condition 1-2 hours test exterior quality.Measurement satisfied with electrical and mechanical performance normal.
    Resistance constant hot and humid testRelative humidity:95±3%,Test temperature: 40℃,last 2 hours ,put it after 5 min test the electrical function .Test products during common condition 1-2 hours ,Then test exterior quality.Measurement satisfied with electrical and mechanical performance normal.
    Vibration testVibrate Frequency:10-55HZ;
    Distance :0.35mm;Acceleration :50.0m/s;Sweep frequency cycle:30 times
    Vibration test
    Fall testFrom 1m height fall down 3 times freely (vertical direction)Electrical and mechanical performance normal



    Shipment:


    • When you place an order,please choose a shipping method and pay for the order including the shipping fee.Generally,we will send the items as soon as possible once your payment is completed.
    • We do not guarantee delivery time on all international shipments due to differences in customs clearing times in individual countries,which may affect how quickly your product is inspected. Please note that buyers are responsible for all additional customs fees,broderage fees,duties,and taxes for importation into your country.These additional fees may be collected at time of delivery.We will not refund shipping charges for refused shipments.
    • We are not responsible for any custom duty or import tax.
    • The shipping cost does not include any import taxes,and buyers are responsible for customs duties. I understand that you are worried about any possible extra cost for the items.Based on past experience.



    FAQ:

    • Is there any tracking Number for my item?

      Yes, we ship every order with their Tracking Number, and you can view the shipment staus on the corresponding website.

    • Is the product same as photos?

      Yes, all photos are real. We took these photos by ourselves.


    • Which size can fit me?

      We suggest you look at our size suggestion chart below and our product size chart if you are normal figure. if you have special figure, please contact us ( tell us your height and weight, bust, waist, hip size ).


    • Can you declare lower value?

      Yes, usually we'll declare $10-$20 for small parcels (1-5 pcs). If you have special request please contact us.


    • I am a reseller,I would like to buy many pieces of your item, what's the wholesale price?

      Hi,thanks for your inquiry, if you would like to buy large quantity, please send email to
      us, we will give you the best price, thanks!




    Returns:


    • We do our best to serve our customers the best that we can.
    • The buyer should make sure that the items returned are in their original conditions.If the items are damaged or lost when they are returned.the buyer will be responsible for such damage or loss, and we will not give the buyer a full refund. The buyer should try to file a claim with the logistic company to recover the cost of damage or loss.
    • The buyer will be responsible for the shipping fees to return the items.
